Forklifts
SLF1000
General Information
Compact, practical and built around the operator. The machine is designed for tight working areas, with a short tail swing, an adjustable seat and easy-access service points.
Power comes from a water-cooled four-cylinder diesel engine matched to a load-sensing hydraulic system, so the machine stays productive without burning more fuel than the job needs.
Every unit is pre-delivery inspected, photographed and container planned before shipment, and ships with an English operation manual and a twelve-month warranty on major components.
Technical Specifications
| Power unit | Electric | ||
|---|---|---|---|
| Operation | Seated on | ||
| Rated traction weight | 1000 kg | ||
| Load centre | 500 mm | ||
| Axle centre to fork face | 360 mm | ||
| Wheel base | 1250 mm | ||
| Service weight with battery | 1700 kg | ||
| Wheels type | Pneumatic | ||
| Driving wheel size | 500-8-10PR mm | ||
| Bearing wheel size | 400-8-10PR mm | ||
| Wheels, number front/rear | 2×/2 | ||
| Track width | 880 mm | ||
| Track width | 860 mm | ||
| Mast/fork carriage lift, forward/backward | 6/6° | ||
| Height of mast, lowered | 2150 mm | ||
| Free lift | 1225 mm | ||
| Lift | 3000 mm | ||
| Height of mast, extended | 4075 mm | ||
| Height of overhead guard (cabin) | 2140 mm | ||
| Height of seat/stand-on platform | 1100 mm | ||
| Towing coupling height | 370 mm | ||
| Overall length | 3020 mm | ||
| Length to fork face | 1950 mm | ||
| Overall width | 1070/1220 mm | ||
| Fork dimensions | 32/100/1070 mm | ||
| Width of fork carriage | 100 mm | ||
| Min.Ground clearance | 80 mm | ||
| Aisle width with pallet 10001200 across forks Ast | 3970 mm | ||
| Aisle width with pallet 8001200 along forks Ast | 4100 mm | ||
| Min.Turning radius Wa | 2185 mm | ||
