Golf Carts
SLGA04
General Information
Compact, practical and built around the operator. The machine is designed for tight working areas, with a short tail swing, an adjustable seat and easy-access service points.
Power comes from a water-cooled four-cylinder diesel engine matched to a load-sensing hydraulic system, so the machine stays productive without burning more fuel than the job needs.
Every unit is pre-delivery inspected, photographed and container planned before shipment, and ships with an English operation manual and a twelve-month warranty on major components.
Technical Specifications
| Outside Dimension | 3250*1350*2050 mm | ||
|---|---|---|---|
| Passengers Capacity | 4 | ||
| Max.Speed | 40km & 25mph/h | ||
| Max.Travelling Range | 80-100 km | ||
| Slope Climbing Capacity | 30% | ||
| Turning Radius | 4 m | ||
| Ground Clearance | ≥125 mm | ||
| Brake Distance | ≤4 m | ||
| Wheelbase | 2440 mm | ||
| Front/Rear Tread | 940/1030 mm | ||
| Weight | 600 kg | ||
| Tire | 20*10-12,with aluminium alloy wheel rim | ||
| Motor | 4kw,5kw,7.5kw | ||
|---|---|---|---|
| Controller | 48V, 60V, 72V | ||
| Battery Type | Lead acid battery、Lithium iron phosphate battery | ||
| Charger | Intelligent high-frequency car charger | ||
| Charging Time | 6-8 hours | ||
| Braking System | Front/Rear Disc Brake,EMB system | ||
|---|---|---|---|
| Front Axle and Suspension | Independence suspension | ||
| Rear Axle and Suspension | Torsion beam | ||
| Steering | *Rack &Pinion*Steering | ||
| Display | LCD instrument,show time,speed,driving range, battery capacity,etc | ||
|---|---|---|---|
| Light | Front &rear combination LED lights | ||
| Seat | Bus cold foam sponge +high-resilience PU leather fabric | ||
| Body Material | Steel frame +ABS engineering plastic moldingmaterial | ||
Gallery
