| Type of Motor | 1500W (60H) 1800W/2000W Optional |
|---|
| Controller | 24 Tubes 28/32 Tubes Optional |
|---|
| Battery Types | Lead-acid/Lithium Battery 60V-72V Optional |
|---|
| Front/Rear Wheel | Front: 4.50-12, Rear: 4.50-12 (5.00-12 Optional) |
|---|
| Front Shock Absorber | 43 Outer Spring Shock (50 Outer Spring Optional) |
|---|
| Front and rear brakes | Front: 130 Drum Brake, Rear: 180 Drum Brake (Disc Brake Optional) |
|---|
| Leaf Spring | 8 Leaves |
|---|
| Overall Dimension | 3360*1360*1420(mm) |
|---|
| Cargo Box Size | 1800*1300 (mm) |
|---|
| Wheel Base | 2200(mm) |
|---|
| Wheel Track | 1150(mm) |
|---|
| Min. Ground Clearance | 200(mm) |
|---|
| Max. Speed | 45(km/h) |
|---|
| Range | 50-100(km) Calculated based on battery capacity |
|---|
| Kerb Weight without battery | 320(Kg) |
|---|
| Max Rated Load | 1200(Kg) |
|---|
| Basic Functions | 3-Speed Shift, Climb Gear, Reverse |
|---|
