| Electric Controller | 60V 350A 3-phase asynchronous AC controller, CMOS stepless speed change system, with automatic electronic braking and anti-skid functions |
|---|
| Motor | 60V 5kW 3-phase AC asynchronous high-efficiency copper winding motor, high torque, low noise |
|---|
| Battery | 60V 105Ah Lead-acid Battery |
|---|
| Charger | Input AC220V, output voltage staged output according to battery charging curve |
|---|
| Charging Time | 10 hours |
|---|
| Body | High carbon steel frame (PP composite material injection molded front cover), excellent impact resistance |
|---|
| Chassis | High-strength steel frame type longitudinal beam chassis, electrophoretic coating + powder spraying anti-rust treatment |
|---|
| Seat | Foam cushion, ergonomic design |
|---|
| Lights & Signals | LED high/low beam lights, turn signals, rear combination taillights, horn, reversing buzzer |
|---|
| Steering System | Ball-joint steering mechanism |
|---|
| Brake System | Front disc brake + rear drum brake + foot parking brake |
|---|
| Front Axle & Suspension | MacPherson independent front suspension, coil spring + telescopic hydraulic shock absorber |
|---|
| Rear Axle & Suspension | Integral rear axle, composite leaf spring + telescopic hydraulic shock absorber |
|---|
| Tire | 23*10-14 inch, steel rim |
|---|
